PIC18F46K22 Controller Board

Our PIC18F46K22 Controller Board is based on the Microchip® High-Performance PIC18F46K22 Microcontroller. This unit features a large 64k of Program Memory as well as a massive 30 Channels of 10-bit A/D Converters, making the PIC18F46K22 Controller ideal for real world monitoring applications where are a large number of A/D inputs are required. The unit can be programmed and debugged using the Microchip® debugging tools and programs can be developed in C or assembly langauge.

The PIC18F46K22 Microcontroller is loaded with features, including an optimized core for high speed operation. Full linear program memory addressing for the full 64k of program memory. Hardware implemented 8 x 8 Multiply instruction enabling high speed operation up to 16 MIPs. Charge Time Measurement Unit is included for capacitive touch sensing and for touch screens. Up to 30-Channels of 10-bit A/D Converters are included together with 5 Capture/Compare Modules and 2 USART ports. Up to 36 I/O points are available with all port connectors brought out to standard headers for easy connect and disconnect. In-Circuit program download is also provided, enabling the board to be easily updated with new code and modified as required, without the need to remove the microcontroller.

All the necessary support components are included, together with a Power and Programming LED for easy status indication. A Program-Run switch is provided for easy program download together with LED indication. Programs can be downloaded using the Microchip® ICD Debuggers and also our PIC Programming Unit. A test LED is also included with a pushbutton and A/D variable input for testing and developing your programs.

The PIC18F46K22 Controller is ideal for small embedded applications requiring a large number of A/D inputs. The PIC18F46K22 Controller will easily fit in a small project box and can be easily integrated as a stand-alone controller or real-world monitoring node.


Part Code: PIC18F46K22CONT


Features

  • Includes Powerful Microchip PIC18F46K22 Microcontroller with 64Kbyte Memory
  • Operating Speed up to 16 MIPS
  • Direct In-Circuit Programming and Debugging with Microchip® ICD2 and ICD3
  • Up to 36 I/O points with easy to connect standard headers
  • Two I²C and SPI Channels
  • Two RS232 Connections
  • Internal EEPROM
  • Huge 30 Channels 10-bit A/D Convertors
  • Four 16-bit Timers and Three 8-bit Timers
  • Power and Programming LED
  • Reset Button
  • On-Board Regulator for 3.3V
  • Ideal as an Interchangeable Controller for Real-Time Systems


Terrific Value at only $28.90
