PIC16F628 Controller Board

Looking for an inexpensive compact mini-controller. Our PIC16F628 Controller is ideal as a mini controller. This board is based on the Microchip PIC16F628A microcontroller and has a host of useful peripherals. Ideal for those situations, when a full 40 pin controller is not necessary and a smaller compact controller will fit the job nicely. This board comes complete with a LCD Connection, RS232 Communication, direct in-circuit program download and much more.

The PIC16F628 Microcontroller includes 2kb of internal flash Program Memory, together with an internal EEPROM for storage of permanent values. Also included within the microcontroller are 2 analog comparators, 1 USART, 3 timers and a capture-compare module. Port connections are brought out to easy to connect standard IDCC connectors, for each connection and disconnection. A MAX232 is included for transferring data to an from a serial port connection, such as a computer or modem.

All the necessary support components are included on the board, together with a Power and Programming LED for easy status indication. Plus a reset switch for program execution. Programs can be updated and downloaded directly to the board, through the download connection on-board. A parallel port connection is required for program downloads.

The new PIC16F628 Controller is the ideal mini-controller, where a low-cost, easy to use controller is required for the less intensive applications. This board is delivered ready-to-run and can easily fit into an existing system or as the main controller for a variety of systems, including burglar alarms, remote sensors and much more.


Part Code: PIC16F628CONT


Features

  • Includes Microchip PIC16F628 Microcontroller with 2kb Internal Flash Program Memory
  • Operating Speed at 10MHz
  • Direct In-Circuit Programming for Easy Program Updates
  • Up to 10 I/O points with easy to connect standard headers
  • RS232 Connection with MAX232
  • Internal EEPROM
  • LCD Connection with Contrast Adjustment
  • One 16-bit Timer with Two 8-bit Timers
  • Power and Programming LED
  • Reset Button
  • Ideal as an Interchangeable Controller for Real-Time Systems


Terrific Value at only $17.90
