74HC75 Features
- Standard 16-Pin DIP IC
- Designed as a Temporary Storage for Binary Information
- Latches Feature Complementary Q Outputs
- Fast Switching Speed
- Operating Temperature up to 70°C
- High-Speed CMOS Type
Description
The 74HC75 contains two independent 2-bit bistable transparent latches.
Each of the 2-bit latches are controlled by separate Enable inputs. When the
Enable input is HIGH, data enters the latch and appears at the Q output. When the
Enable input is LOW, data is not passed through to the latch.
|
Part Summary
|
|
Manufacturer
|
Various
|
|
Manufacturer's Part Number
|
74HC75
|
|
Manufacturer's Web Site
|
-
|
|
Futurlec Part Number
|
74HC75
|
|
Department
|
Integrated Circuits
|
|
Category
|
74HC Series
|
|
RoHS Compliant
|
Yes
|
|
Package Type
|
16 Pin DIP
|
|
Technical Data
|
74HC75 Datasheet
|
