74LS154 4 to 16 Line Decoder/Demultiplexer
74LS154 Features
- Decodes 4 binary-coded inputs into one of 16 mutually exclusive outputs
- Performs the demultiplexing function by distributing data from one input line to any one of 16 outputs
- Input clamping diodes simplify system design
- High fan-out, low-impedance, totem-pole outputs
- Typical power dissipation 45 mW
|
Part Summary
|
|
Manufacturer
|
Various
|
|
Manufacturer's Part Number
|
74LS154
|
|
Manufacturer's Web Site
|
-
|
|
Futurlec Part Number
|
74LS154
|
|
Department
|
Integrated Circuits
|
|
Category
|
74LS Series
|
|
RoHS Compliant
|
-
|
|
Package Type
|
24 Pin DIP
|
|
Technical Data
|
74LS154 Datasheet
|
|
Ordering
|
|
Pricing Unit
|
1
|
|
Package Qty
|
1
|
|
Minimum Order Quantity
|
1
|
|
|
