Silicon Chip October 2015

In this October issue of Silicon Chip Magazine build an Arduino Based USB Electrocardiogram. This unit is ideal for medical students and fitness professionals. The unit is built on a standard size Arduino shield and connects to your laptop via a USB cable to display your own ECG waveforms. The unit features the Analog Devices AD623 Instrumentation Amplifier IC at the front-end to provide high common-mode signal rejection and high gain, ensuring accurate and reliable readings. The shield together with an Arduino Uno board as the base is housed in a solid diecast box. The monitoring software and program software is available for free on the Silicon Chip website and once completed, you will have a professional looking ECG monitoring unit.

Also this month, build the 110W Version of the Ultra-LD Power Amplifer, for those wanting a lower cost module and do not require the full 200W version, this is a cheaper alternative, whilst retaining the high-performance specs of the larger unit. Finally this month, build a 5-Element FM Antenna, ideal for those in remote areas, who want to ensure they receive the best possible signal for their FM listening pleasure, this 5-element Yagi antenna produces amazing results. All projects come complete with circuit diagram and electronic parts list.

In this month’s articles, a look at the developing technology of computational photography. Conventional cameras are limited in terms of focus and perspective when taking pictures. Computational photography combines conventional camera shots with computers to produce highly accurate and evenly exposed pictures. Also this month, a look at a Hybrid Solar System, that provides power storage for use during the evenings and for blackouts, as well as delivering power back to the grid when the batteries are fully charged.

Part Code: SILCHIPOCT2015

Features

What is Computational Photography
A Large Real-World Hybrid Solar System
Immortus: Australian Concept Electric Vehicle

Projects

Ultra Low-Distortion 200W RMS Power Amplifier, Part 3
An Arduino-Based USB Electrocardiogram
A 5-Element Antenna for Better FM Reception
2-Way Crossover for Senator 10-inch Loudspeakers
