Silicon Chip May 2015

In this month’s Silicon Chip Magazine, build a professional quality Appliance Earth Leakage Tester. This unit can be used to check the safety of earthed and double insulated equipment. Also the unit can be used when the equipment is powered by the mains. Ideal for servicemen, the unit provides a quick safety check of equipment to leaks to ground or faulty insulation.

Also this month, build a 2-Channel Balanced Input Attenuator for Audio Analysers and Digital Scopes. This unit can be used to extend the measurement capabilities of low cost USB test instruments like the QA400 Stereo Audio Analyser. It provides balanced/differential inputs for each channel in addition to unbalanced inputs, combined with three attenuation/measurement ranges of 1:1, 10:1 and 100:1. Finally, this month the third part of the Arduino Weather Station, this month build the receiver unit for receiving the various sensor signals and then sending them on to your pc, for display in the weather station software. All projects come complete with circuit diagram and electronic parts list.

In this month’s features, a very interesting look at all the different aircraft on display at the Australian International Airshow. A wide range of different aircraft were on display, this article covers the different performance specs of the aircraft plus also a "youtu" link for a closer live view. Also this month, a practical report on Home Solar Panel Electricity Generation, what are the costs, benefits and problems. One reader "took the plunge" and provides a detailed practical report on his experience. Plus all the regular columns, including the Circuit Notebook, Serviceman’s Log and Vintage Radio are included, providing stacks of great reading.

Part Code: SILCHIPMAY2015

Features

The Australian International Airshow 2015
Home Solar Panel Electricity: Is It Worth It?
Review: The Navman MiVue Drive GPS Unit
Review: The MikroElectronika Buggy

Projects

Appliance Earth Leakage Tester
Balanced Input Attenuator for Audio Analyses & Scopes
4-Output Universal Voltage Regulator
WeatherDuino Pro2 Wirelesss Weather Station, Part 3
