Silicon Chip June 2010

Last few copies available of the June Issue of Silicon Chip Electronics Magazine, with a wealth of interesting articles and projects, this magazine is ideal for the electronics enthusiast. This month’s articles, include an interesting look at an Australian manufactured Unmanned Aerial Vehicles (UAV's), the new Silvertone Flamingo. This lightweight UAV can travel at speeds of up to 144km/h and has a maximum ceiling of 4500m together with a flying time of up to seven hours. The plane is currently being used for a wide range of interesting applications, including crop monitoring, planning and mapping, water storage monitoring. Also this month a look at the new 3D camera rig, the SpeedWedge, this new camera allows 3D films to be produced quickly and efficiently.

This month’s projects include a Air-Quality Meter for checking the CO and CO2 levels in your home, boat or caravan. This easy to build unit, displays the CO and CO2 levels in a 15 level bargraph, an audible alarm is also provided if the level exceeds a preset alarm level. A fan is also included to ensure a fresh and accurate suply of air to the sensors mounted inside the unit. Also this month, a useful Dual Tracking Power Supply for your workbench. This professional looking unit, can deliver up to 1.6A and provides an accuracy of within 1% with a full digital display. Ideal for the project builder, this unit can be built with a AC Plugpack input, so no mains wiring is required. Finally this month, another project for the serviceman or electrical contractor, the Digital Insulation Meter is ideal for testing wiring, tools and other forms of insulation. The unit has a selectable test voltage and provides a digital readout of the insulation level. The unit is very easy to use and can be built in several hours. All projects come complete with circuit diagram and electronic parts list.

Part Code: SILCHIPJUN2010

Features

Unmanned Aerial Vehicles, An Australian Perspective
Breakthrough Aussie Innovation: Making 3D Movies
Review: LeCroy WaveAce 112 Digital Storage Oscilloscope

Projects

Air-Quality Meter for Checking CO & CO2 Levels
Dual Tracking Power Supply, Part 1
Build a Digital Insulation Meter
A Solar-Powered Lighting System, Part 2

Sold Out
