Silicon Chip December 2015

In this December Silicon Chip Magazine build a high visibility Large 6-Digit LED GPS Clock. This clock features large blue LED's that can be seen from a considerable distance together with GPS accuracy, as well as time zone detection and daylight saving adjustment. The unit also has automatic dimming, date display, battery back-up and much more, the unit can also be used as a count-up and count-down timer for sporting functions. The unit is based on the Microchip® PIC32 Microcontroller and has the option for program updates with the in-circuit programming adapter. The unit can also be built with red, green or white seven-segment LED Displays.

Also this month, build the Turntable Strobe, for checking your turntable speed for accuracy. It you have a stack of vinyl records and enjoy giving them a spin on your turntable, it is important to periodically check the turntable speed for accuracy, as even small speed changes can affect your listening pleasure. Finally this month, build a Speech Timer for contests and debates, ideal for schools and groups, this unit can count-up and down, as well as giving warning LED indication for when the time is almost up together with a buzzer to indicate the end of the time period. All projects come complete with circuit diagram and electronic parts list.

In this month’s articles, a full report on the Bridgestone World Solar Challenge, this year saw a huge field in a wide range of vehicles with different classes for the various school, university and professional groups. This article looks at some of the cars and the technology behind the designs. Also this month, an interesting article on the largest astronomical image of all time. This picture consists of 46 Billion pixels and has taken 5 years to prepare.

Part Code: SILCHIPDEC2015

Features

The 2015 Bridgestone World Solar Challenge
The Largest Astronomical Image of All Time
Super and Ultra-Super-Critical Steam Power Stations
High Quality Audio Transformers from Sweden

Projects

High Visibility 6-Digit LED GPS Clock
Check Turntable Speed with this White LED Strobe
Speech Timer for Contests and Debates
Arduino-Based Fridge Monitor and Data Logger
