Welcome to Futurlec. The ELECTRONIC COMPONENTS Superstore. To find the component your looking for, either search by Part Number or visit the relative department. Need Help. MAGAZINES Silicon Chip - October 2008 by Silicon Chip Just Arrived the new October Issue of Silicon Chip, with a wealth of interesting articles and projects, this magazine is ideal for the electronics enthusiast. This month's articles, include a look at the new CleverScope CS328A USB Dual Channel Oscilliscope, this neat little unit plugs directly into your PC for viewing and recording of the various data inputs. The unit is suitable for both Analog and Digital Signals with an optional signal generator for testing audio equipment. Also this month using a PICAXE with a RF Transceiver unit for easy transmitting and receiving of data.This month also looks at using a extensively modified microwave oven for a UV exposure box for developing photo-sensitive PC boards. This month's projects include a USB Clock with digital readout, this interesting project synchronizes the time by computer and internet, providing a very accurate time clock. The unit can be set-up and controlled by the computer and will also operate stand-alone with the computer disconnected. Optional backlighting is available, together with a dimming function for reducing power drain. Also this month an attractive new design for a Digital RF Level and Power Meter, this unit is ideal for measuring small radio signals and provides an accurate digital LCD readout. Suitable for measuring signals from 50kHz up to 500MHz. This month also features a special function timer with external triggering for event timing. The unit is easily adjustable and provides relay output, making the unit ideal for controlling mains appliances. The second part of the new Railpower Model Train Controller is also included in this issue, including the construction details and programming the unit. Together with the regular real life tales from the Serviceman's Log as well as the Circuit Notebook and your Questions. Features • CleverScope CS328A USB Dual-Channel 100MHz Scope • Picaxe-08M 433MHz Data Transceiver • Exposing PC Boards In a Modified Microwave Oven • Watching Your Power Consumption Projects • USB Clock with LCD Readout, Part 1 • Digital RF Level and Power Meter • Versatile Special Function Timer • Railpower Model Train Controller, Part 2 Order Now for USD$7.50 Silicon Chip - September 2008 by Silicon Chip This month we have an indepth look at the new high voltage DC power link between Victoria and Tasmania, this is the longest undersea power link in the world and enables power to be transported economically between the two locations. Both states have unique generating capabilities and requirements, this solution provides benefits in both directions. Also a look at the theory behind high voltage DC power transmission. Also a look at the new Metal Instaltest test station, ideal for mobile use with electricians or contractors, this unit measures and tests household wiring and can also generate a report necessary for safety standards. This month's projects include a new model train controller. This unit incorporates a number of new features over previous designs, including an infrared remote control, pulse power for extra smooth low-speed, LCD display with speed indication, simulated inertia and much more. The unit is quite easy to build and is housed in an attractive panel case. The unit is microcontroller based and is designed for use with 240Vac power systems. Also this month a simple LED flasher unit to build, with selectable operation characteristics, plus the assembly details for the high-performance 200W amplifier module, this module is both rugged and features remarkably low-distortion. The fourth part of the DSP Musicolour unit describes the construction of the remote control unit and the second part of the LED Strobe and Tachometer unit, includes the assembly instructions. Plus all the regular great columns. Grab a copy now, at an unbeatable price of only $7.50 Features • The Basslink High-Voltage DC Power Link • Review: Metrel Instaltest 3017 Projects • Railpower Model Train Controller • Versatile LED/Lamp Flasher • Ultra-LD Mk2 Power Amplifier Module, Part 2 • DSP Musicolour Light Show, Part 4 • LED Strobe & Contactless Tachometer, Part 2 Order Now for USD$7.50 Silicon Chip - August 2008 by Silicon Chip Just Arrived the new August Issue of Silicon Chip, with a wealth of interesting articles and projects, this magazine is ideal for the electronics enthusiast. This month's articles, include a look at a newly developed concept of printing in the third dimensions, see your designs come to life, with this new 3D printing process. Also this month a look at the new TekTronix Digital Phosphor Oscilloscope, this unit boasts a huge array of features, including colour and windows-like interfaces. The unit also supports a wide range of digital signal monitoring, including CAN/LIN and I2C buses. This month's projects include a new design for the heavy duty 200W amplifier module. This new unit has excellent performance specs, including very low distortion, Class-AB design with high performance ThermalTrak Power Transistors, as well as smooth and flat frequency response over the audio range. The unit is quite easy to build and is ideal for use with PA and outdoor sound equipment. Also this month, build a radio receiver to pick up the noise originating from Jupiter or the Sun. This unit can be connected to a simple dipole antenna and is based on a single-conversion superhet design. This month also includes a contactless strobe and tachometer unit, for measuring the RPM of rotating machines. Based on a simple Luxeon strobe unit, this compact module includes a digital readout with fine frequency adjustment. Finally this month, Part 3 and the construction details for building the Musicolour unit. This unit boasts a wide range of programming selection options and is equal to the most professional units available today. Together with the regular real life tales from the Serviceman's Log as well as the Circuit Notebook and your Questions. Features • Printing In The Third Dimension • Review: TekTronix DPO3034 Digital Oscilloscope Projects • Ultra-LD 200W Power Amplifier Module • Planet Jupiter Receiver • LED Strobe and Contactless Tachometer • DSP Musicolour Light Show, Part 3 Order Now for USD$7.50 Silicon Chip - July 2008 by Silicon Chip This month we look further into house wiring and the pros/cons of being able to do it yourself. Also an indepth look at the new Agilent MS07034A Mixed Signal Scope, this unit is truly a dream unit, with a huge range of features and high accuracy. This month we also look into the new PICAXE micros that are available. New 8 pin, 14 pin and 20 pin versions are all covered in detail here. This month's projects include the second part of the new DSP Musicolour Light Show kit, this unit will become the life of your party, with a huge range of programmable features, ideal for discos, fashion shows, product demonstrations etc. Secondly, a new PIC-Based Musical Tuning Aid project , this unit can produce any note in the tempered musical scale in any of the eight most commonly used octaves. Ideal for tuning guitars, pianos and other musical instruments. Also this month a microphone pre-amp for PC's and MP3 players, this unit allows you to connect a microphone to your pc for accurate sound recording, without the clipping and feedback, that is often present. Finally a bridge adaptor for stereo power amplifiers. Plus all the regular great columns. Grab a copy now, at an unbeatable price of only $7.50 Features • House Wiring, a Look at Light Switches • Review: Agilent MSO7034A Mixed Signal Oscilloscope • New PICAXE Micro Review Projects • DSP Musicolour Light Show, Part 2 • PIC-Based Musical Tuning Aid • Balanced MIC Preamp for PC's & MP3 Players • Bridge Adaptor for Stereo Power Amplifiers Order Now for USD$7.50 Silicon Chip - June 2008 by Silicon Chip Just Arrived the new June Issue of Silicon Chip, with a wealth of interesting articles and projects, this magazine is ideal for the electronics enthusiast. This month's articles, include a look at household electrical wiring and is it safe for you to do it yourself, we have a look at the standards and law in regard to this issue. Also this month Crash Test Dummies, how are they made and what sensors are fitted and how the data is recorded. An interesting inside into how the testing is performed. This month's projects include a DSP Musicolour unit, this new design incorporates many state of the art features, not available in previous designs. The unit accepts audio input signals and drives the coloured lights in tune with the music. Ideal for discos and light shows, the unit provides different lighting modes and is suitable for both 240VAC and 120VAC power systems. Also this month a versatile Flexitimer for switching loads according to different time intervals, the unit has programming ON and OFF times as well as continuous cycling options. Timing accuracy is quite high and the relay output is suitable for switching a wide variety of loads. Finally this month a useful power supply for external hard drives, great for cases when the USB port is not able to provide sufficient power. Plus a Balanced/Unbalanced Converter for Audio applications, this unit balances long signal runs to prevent hum and noise pick-up. Together with the regular real life tales from the Serviceman's Log as well as the Circuit Notebook and your Questions. Features • DIY Electrical Work • A Look at Crash Test Dummies • Review: Altitude 2500-SS Stereo Valve Amplifier Projects • DSP Musicolour Light Show • PIC Based Flexitimer Mk4 • USB Power Injector for External Hard Drives • Balanced/Unbalanced Converter for Audio Signals • A Quick'n Easy Digital Slide Scanner Order Now for USD$7.50 Silicon Chip - May 2008 by Silicon Chip This month a wealth of useful technical articles for the engineer and hobbyists. Firstly, the new Vectrix Electric Motor Scooter, the first production fully battery-powered road vehicle, this great new bike runs completely on battery power and is suitable for speeds up to 100km/h as well as a range of 110km. Ideal for wizzing around town, we have a detailed look at the design and performance of this environmentally friendly motor scooter. Also this month an inside test of another "Power Saving" device, does it really work and are the claims of up to 24% power savings valid. This month's projects includes a replacement CDI Module for small electric motors, ideal for ride-on mowers, motorbikes, outboard motors and much more. This unit costs less then $50 to make and can be easily built with only a few parts. Also this month a new High-Accuracy Digital LC Meter, This unit is able to measure inductances from 10nH to 70mH and capacitances from 0.1pf to 800nF, the unit features a digital panel readout as well as adjustable contrast and high sampling rate. Finally a low cost dsPIC and PIC programmer for dip PIC parts, this unit only requires a few parts and includes ZIF sockets for easy part programming and removal. Also a adjustable voltage regulator for operating a CD, DVD or MP3 player from your cigarette lighter socket. Plus all the regular great columns. Grab a copy now, at an unbeatable price of only $7.50 Features • The Vectrix Electric Scooter • The Enersonic Power Saver • Prototype PC Boards Projects • Replacement CDI Module for Small Petrol Motors • High Accuracy Digital LC Meter • Low Cost dsPIC/PIC Programmer • High Current Adjustable Voltage Regulator Order Now for USD$7.50 Silicon Chip - April 2008 by Silicon Chip Just Arrived the new April Issue of Silicon Chip, with a wealth of interesting articles and projects, this magazine is ideal for the electronics enthusiast. This month's articles, include a look at the new UltraCapacitors available, these are set to revolutionize power storage and are ideal for portable appliances and electric cars. Also this month the second part of our article on Digital TV, the antenna required is covered in detail, together with the various options available. This month's projects include a very useful 12V charge controller for your Lead-Acid or SLA Batteries. This unit is suitable for up to 10A and includes cyclic and floating charging. Temperature compensation is included together with LED indication for Charge, Absorpion and Float cycles. The unit is solidly constructed and is suitable for long life operation, the unit is designed to work from a 240Vac supply. Also this month a safe flash trigger for an external electronic flash, protect your digital SLR camera, with this safe triggering device. Included also is the second part of the 12-24V DC Motor Speed Controller project, then month we cover the construction and testing of this unit. Finally, this month a Two-Way Stereo Adapter for use when there is no available headphone socket on your stereo unit. Together with the regular real life tales from the Serviceman's Log as well as the Circuit Notebook and your Questions. Features • Beyond the Capacitor there is the Ultracapacitor • How To Get Into Digital TV, Part 2 Projects • Charge Controller for 12V Lead-Acid or SLA Batteries • A Safe Trigger for your Digital SLR Camera • 12-24V High Current DC Motor Speed Controller, Part 2 • Two-Way Stereo Headphone Adaptor Order Now for USD$7.50 Silicon Chip - March 2008 by Silicon Chip This month a wealth of useful technical articles for the engineer and hobbyists. Firstly, Digital TV has arrived, we look at what is required and how to set-up your system. For the constructor, an excellent article on soldering surface mount devices, this article covers all the basics, as well as providing an easy solution for reflow soldering. For the design engineer, a quick introduction to the I&sub2;C bus, how to use it and some of the problems you will face. Finally an interesting article on battery-powered flight, a new milestone for clean air technology. This month's projects includes a high current DC Motor Controller, this unit is suitable for both 12 and 24V DC Motors and can deliver up to 40A. It features speed regulation under load, soft-start and fast switch-off, eight memory settings with pulse width modulation (PWM) for speed control. This unit is equivalent to much more expensive commercial units currently available. Also this month, a variable frequency oscillator (VFO) built with a readily available recycled Nokia LCD to display analogue and digital frequency readings. This month, also build a simple LPT-to-I&sub2;C interface for quick debugging of your I&sub2;C network, as well as a simple 1 pulse per second digital signal for quartz clocks. Plus all the regular great columns. Grab a copy now, at an unbeatable price of only $7.50 Features • How To Get Into Digital TV • How To Solder SMD's • The I&sub2;C Bus: A Quick Primer • Electric Flight • Review: Tevion TEV8200 HD Set-Top Box Projects • 12-24V High-Current DC Motor Speed Controller, Part 1 • A Digital VFO with LCD Graphics Display • A Low-Cost PC-to I&sub2;C Interface for Debugging • One Pulse Per Second Driver for Quartz Clocks Order Now for USD$7.50 Silicon Chip - February 2008 by Silicon Chip Now available the latest February issue of Silicon Chip. This month features a great article on how a Toyota Prius was modified to achieve an incredible 100 MPG with the addition of a Lithium-ion Battery Pack. The battery pack were easily accommodated in the boot of the car with only a few modifications needed to the electronic system to achieve this remarkable fuel consumption. Also this month we review the new ATTEN Digital Storage Oscilloscope, this is a top of the range unit featuring a high sampling rate. This month's projects include a wide range of remote control power switches. Want to control any mains appliance with a simple UHF Remote Switch, this unit is capable of switching loads up to 1.87kW and up to 10 units can be controlled, by setting different ID's for each unit. The unit will operate up to a distance of 200m, making it ideal for switching an external pump or garage light. Also this month a PIR triggered Mains Switch, this unit is capable of switching a device when a person approaches. Ideal for external lighting or a door bell, also for switching a recording device when movement is detected. This month also a simple shift indicator and rev limiter for cars and a mini solar battery charger with high efficiency. Together with the regular real life tales from the Serviceman's Log as well as the Circuit Notebook and your Questions. Features • How To Get More Than 100MPG from a Toyota Prius • Review: ATTEN ADS7062CA Digital Storage Scope • Picaxe VSM Circuit Simulator, Part 2 Projects • UHF Remote-Controlled Mains Switch • UHF Remote Mains Switch Transmitter • PIR Triggered Mains Switch • Shift Indicator & Rev Limiter for Cars • Mini Solar Battery Charger Order Now for USD$7.50 Silicon Chip - January 2008 by Silicon Chip This month we review the new Denon Compact Disc Player, this unit is ideal for hi-fi enthusiasts and features excellent playback performance. Also we look at the new PICAXE VSM software for circuit simulation of your PICAXE project. Develop and test your PICAXE circuit without needing to set-up any parts. This month's projects includes the new high-performance swimming pool alarm. Ideal for protecting your pool from the possibility of a drowning by an infant falling into the pool. This unit monitors the wave height caused by a disturbance in the pool and will sound an alarm when this exceeds a certain level. The unit automatically resets, and can be easily installed and built, with a minimum number of components required. Also this month an emergency lighting controller, thus unit switches on 12V emergency lighting as soon as the power fails, ideal for workshops, main living areas etc. The unit uses a power pack supply and can be used on a number of different voltage systems. This month also build a 3-Valve radio receiver, this unit uses easy to find valves and is a great educational project, for those restoring old receivers. Finally this month the 3rd portion of the Water Tank Level Meter and a simple 455kHz Modulated Oscillator to build. Plus all the regular great columns. Grab a copy now, at an unbeatable price of only $7.50 Features • Picaxe VSM Circuit Simulator • Review: Denon DCD-700AE Compact Disc Player Projects • Swimming Pool Alarm • Emergency 12V Lighting Controller • Build The "Aussie-3" Valve AM Radio • The Minispot 455kHz Modulated Oscillator • Water Tank Level Meter Pt.3: The Base Station Order Now for USD$7.50
