7SRG40011ASG - Single Red-Green 4.0" 7-Segment Common Cathode Display Technical Data - Buy 7SRG40011ASG

Multi-Color Type

Ideal for Switching Colors as Warning Indication

Easy to Read

RoHS Compliant

Display

• Digit Size: 4.0"
• Material: GaAlAs/GaAs
• Emitted Color: Hi-Red / Green
• Dominant Wavelength: 660 nm / 574 nm

Absolute Maximum Ratings

• Reverse Voltage(Vr): 5 V
• Reverse Leakage Current (Ir): 20 µA
• Forward Current (If): 25 mA
• Peak Forward Current (Ifp): 150 mA
• Power Dissipation (P): 60 mW per Segment
• Operating Temperature (Topr): -40°C to +80°C
• Storage Temperature (Ttsg): -40°C to +85°C
• Lead Soldering Temperature : 260°C

Electro-Optical Data (@ 20mA)

• Forward Voltage - Typical: 9.25V
• Forward Voltage - Maximum: 11.00V
• Luminous Intensity - Minimum per Segment: 288 mcd
• Luminous Intensity - Typical per Segment: 432 mcd
• RoHS Compliant: Yes
